6S-FILL-TOP - Semi-automatic bottle and vial filling machine
6S - FILL - TOP
The semi-automatic filling machine made of stainless steel is designed to be modular and highly adaptable, specifically designed for the semi-automatic filling of bottles and vials. The machine has a cumulative table for automatic introduction to the filling phase and an accumulation table at the exit.
It offers the user optimal flexibility to operate with different formats effectively.
This equipment is prepared for the use of peristaltic or piston pumps, thus ensuring optimal precision in the filling process.
PACKAGING
DESCRIPTION
Constructed of stainless steel and in full compliance with rigorous cGMP and FDA quality guidelines, this device provides reliability and meets regulatory requirements at every stage of the filling process to ensure the highest level of quality and safety required in the pharmaceutical industry. .
For closing and dosing bags, this machine offers different technologies, providing versatility in its functions. In addition, it is equipped with a system that allows quick format changes and an intuitive recipe management interface, which considerably simplifies its use.
Manufactured to rigorous cGMP and FDA standards, this machine is ideal for the pharmaceutical sector, where quality and precision are essential.
BENEFITS
-
Precision in dosage.
-
Anti-drip at the end of the dosage.
-
Compact Size
-
Servomotorized dosage control.
-
Quick recipe change to boost operational efficiency.
-
Simple setup that allows for quick deployment.
-
Easy data extraction for detailed and accurate analysis.
-
Pharmaceutical design for easy cleaning
-
Compatible with insulator system
-
Use of servomotorized technology to improve precision
TECHNICAL INFORMATION
Packaging type:
VIAL - BOTTLE - EYEPIECE - NASAL
Packaging feature:
GLASS
PP
Container dimensions:
DIÁMETRO (ø): 60mm ALTO (H): 120mm
Dosage:
0,1ml – 500ml
Precision:
1 %
Speed:
1.500 uph
Función antigoteo:
Si
Dosing Technology:
Servomotorized peristaltic
Servomotorized Piston
Control:
Control: INDUSTRIAL PLC
Screen: HMI 7"
ENGINES: SERVOMOTORIZATION
Machine Type:
Simple
Doble
Construction Material:
STAINLESS STEEL AISI-304 POM
Feeding:
110/230 VAC- 50/60 Hz
Weight:
60 KG
Measures:
Estándar: 659 mm x 897 mm (LxB)
Aislador: 559 mm x 797 mm (LxB)
Certification:
cGMP - FDA - CE - UL
Optional:
- Mobile Stainless Cart.
- AISI-316L Stainless Peristaltic Head
- AISI-316L Stainless Piston
- Bag Support
- Structure made of AISI -316L
- Compatible with isolator system
- IQ/OQ validation
- CFR21 PART 11
